Access Layers

Authentication and.Access

Users require an account in LDAP and be member of th eusers_users group

OVH Service

Single IP

Public IP

Tailscale IP

Tailscale: tailnet

`100.100.69.0/16`

Docker Network: proxy

`172.22.20.0/16`

Docker Netwpork: Admin

`172.22.20.0/16`

Docker

/home/apps/core

 - ./api.notflix.pknw1.co.uk/docker-compose.yml
 - ./caddy/docker-compose.yml
 - ./internal-proxy/docker-compose.yml
 - ./proxymanager-admin/docker-compose.yml
 - ./dockmon/docker-compose.yml
 - ./lldap/docker-compose.yml
 - ./proxymanager/docker-compose.yml
 - ./squid/docker-compose.yml
 - ./pihole/docker-compose.yml

Service

Docker

api.notflix proxy/172.22.20.1
dmz/172.22.21.1
admin/172.22.22.1
caddy proxy/172.22.20.1
dmz/172.22.21.1
admin/172.22.22.1
internal_proxy proxy/172.22.20.1
dmz/172.22.21.1
admin/172.22.22.1
proxymanafer proxy/172.22.20.1
dmz/172.22.21.1
admin/172.22.22.1
proxymanager-admin proxy/172.22.20.1
dmz/172.22.21.1
admin/172.22.22.1
dockmon proxy/172.22.20.1
dmz/172.22.21.1
admin/172.22.22.1
lldap proxy/172.22.20.1
dmz/172.22.21.1
admin/172.22.22.1
pihole proxy/172.22.20.1
dmz/172.22.21.1
admin/172.22.22.1
squid proxy/172.22.20.1
dmz/172.22.21.1
admin/172.22.22.1

/home/apps/frontend

/home/apps/backend

/home/apps/user-apps

/home/apps/admin-apps
